Model NO.
5mm Round
Delivery:
FOB Shenzhen
Minimum order quantity:
10000 pieces
Supply Ability:
500kk pieces / Month
Country of Origin:
China
Stock Time:
10 Days
Quantity:

Professional outdoor traffic indicator series Anti-red ink,

anti-UV yellowing, anti-cold shock High TG point,

high temperature resistance,

low light decay Imported original

Osram/Epistar/Thai Valley / chip

2 pins led diode bulbs basic info.

ParameterUnitsMAX
Power Dissipation mW80/100
Peak Forward Current
(1/10 Duty Cycle,0.1ms Pulse Width)
mA150
Continuous Forward CurrentmA30
Derating Linear From 50mA/0.4
Reverse VoltageV5
Operating Temperature Range-40 to +85
Storage Temperature Range-40 to +105
Lead Soldering Temperature260 for 5 Seconds
Part No.Emitting ColorVoltageCurrentIv(mcd)WavelengthAngle
BND-668red1.8-2.2V20mA8000-12000625-630nm30
BND-668Amber&Yellow1.8-2.2V20mA8000-12000588-592nm30
BND-668blue3.0-3.4V20mA8000-12000-15000465-470nm30
BND-668green3.0-3.4V20mA20000-30000515-520nm30
BND-668white3.0-3.4V20mA15000-20000-250002700-12000K30

Spec. of Series products:

1. Size: 3mm,5mm, 8mm,10mm

2. Shapes: Round,Flat,Square,Straw hat,Super Flux

3. Emitting color: red,green,blue,white,yellow,pink,purple,amber,warm white,RGB

4. Beam Angle: 15,25,30,45,60,90,120 degrees

5. Wave length: 395-630nm

6. Forward Voltage: 1.8-2.2V for red,yellow,and amber color,2.8-3.4V for white,blue,green,pink,warm white,purple

7. Forward Current: 20mA

8. Lens colors: water clear,color diffused

9. Life Span: 50,000HRS

10. Packing: 1000Pcs/bag

11. With CE/ROHS/ISO9001:2000 Approved

APPLICATIONS


APPLICATION SCENARIOS:
High quality LED encapsulation of many specification are
widely used in LED electronic display screen,traffic lights,
indicator lights,automobile lamps and lanterns,medium size
back light,communications equipment,commercial lighting,
decorative lamps,home lighting,and other fields.
