TOP LED PLCC-4 SMD 3528 RGB
TOP LED PLCC-4 SMD 3528 RGB
TOP LED PLCC-4 SMD 3528 RGB
TOP LED PLCC-4 SMD 3528 RGB
TOP LED PLCC-4 SMD 3528 RGB

TOP LED PLCC-4 SMD 3528 RGB

Model NO.
BDB-B4RGB-000000
Quantity:

Product Parameters

Product TypePart NumberColorWLD(nm)/
CCT(k)		IV(mcd)VF(v)IF(mA)ESDViewing
Angle (°)

3528 PLCC-4 RGB SMD LED
BDB-B4RGB-000000
 		Red620–630450–9101.8–2.420≥2 kV120°
Green520–535910–14602.6–3.420≥2 kV120°
Blue460–472360–5602.6–3.420≥2 kV120°

Test conditions: IF as listed for each part, Ts = 25°C, RH = 60%. Luminous intensity and electrical ranges depend on the selected BIN.

Dimensions

Nominal package footprint: 3.5 × 2.8 mm. Refer to the corresponding datasheet for mechanical drawing, tolerances and height.
